Space-Saving End of Aisle Rack Protectors

Handle It Space Saving Rack Protectors are installed at the end of rack aisles. The unique design allows you to install the guards around the rack legs saving you space especially where driving lanes are tight. The low profile guard also saves space on your first pallet position. Space saving rack protectors are ideal when space is tight.

Special notched design nests the guard closer to the frame saving floor space

Low profile 12” guard doesn’t block the first pallet bay

Heavy duty 3/8″ thick steel

Buy Online Request a Quote

Overview

  • Guard your warehouse racks, product, and people with Handle It end of row guards.
  • Heavy duty design 3/8” thick material
  • Low Profile guard saves space on your first pallet position
  • Notched angle design saves floor space at the end of your aisles
  • Welded Guards Single or Double Ended, in 42″ or 48″ lengths
  • Powder coated Handle It yellow for high visibility
  • Custom sizes available

BENEFITS

  • Low profile design save vital space especially in tunnel aisles and where oversized lifts are used with tight aisle tolerances
  • The formed guard doesn’t take up space on the first pallet bay position
  • There is a mounting point in the nose of the guard increasing holding power at the most important place, at the corner of the upright.

Literature

Space Saving Rack Guard Product Sheet

Standard Rack Baseplate Dimension Worksheet

Seismic Rack Baseplate

Specifications

Left Hand Style

Right Hand Style

Double Sided Style

Part Number Ext. Length Angle Dims. Notch Clearance Guard Height Thickness OrientationWeight
IRP-42LH-HD 42 6X49" 12" .375 Left61
IRP-42RH-HD 42 6X49" 12" .375 Right61
IRP-48LH-HD 48 6X49" 12" .375 Left 66
IRP-48RH-HD 48 6X49" 12" .375 Right66
IRP-42-HD 42 6X49" 12" .375 Double82
IRP-48-HD 48 6X49" 12" .375 Double92
RP-42EX-HD 42 6X4.375 Extender38
RP-48EX-HD 48 6X4.375 Extender42
RP-62EX-HD 62 6X4.375 Extender59

FAQ

Videos

Guarantee/Warranty

Personal and professional customer service is offered on all Handle It™ products. Our Space-Saving Rack Protectors carry a three-year limited warranty on all materials and workmanship.
